拖链代码 |
Bi[mm] |
Ba[mm] |
R[mm] |
重量[kg/m] |
| G80.075.R | 75 | 125 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 6.30 |
| G80.100.R | 100 | 150 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 6.45 |
| G80.125.R | 125 | 175 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 6.59 |
| G80.150.R | 150 | 200 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 6.74 |
| G80.175.R | 175 | 225 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 6.88 |
| G80.200.R | 200 | 250 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 7.03 |
| G80.225.R | 225 | 275 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 7.18 |
| G80.250.R | 250 | 325 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 7.32 |
| G80.300.R | 300 | 350 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 7.62 |
| G80.350.R | 350 | 400 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 7.90 |
| G80.400.R | 400 | 450 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 8.20 |
| G80.450.R | 450 | 500 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 8.48 |
| G80.500.R | 500 | 550 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | ≈ 8.78 |
