拖链代码 |
Bi[mm] |
Ba[mm] |
R[mm] |
重量 [kg/m] |
| G34H.050.R | 50 | 72 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.52 |
| G34H.075.R | 75 | 97 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.60 |
| G34H.100.R | 100 | 122 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.67 |
| G34H.125.R | 125 | 147 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.74 |
| G34H.150.R | 150 | 172 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.82 |
| G34H.175.R | 175 | 197 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.89 |
| G34H.200.R | 200 | 222 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 1.96 |
| G34H.225.R | 225 | 247 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 2.04 |
| G34H.250.R | 250 | 272 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 2.11 |
| G34H.275.R | 275 | 297 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 2.18 |
| G34H.300.R | 300 | 322 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 2.26 |
| G34H.350.R | 350 | 372 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 2.40 |
| G34H.400.R | 400 | 422 | 063 | 075 | 100 | 125 | 150 | 175 | 200 | 225 | 250 | 300 | ≈ 2.55 |
