| 产品代码 | Bi | Ba | R | 重量 |
| 拖链 | [mm] | [mm] | [mm] | [kg/m] |
| TCH60M.075.R | 75 | 101 | 135|150|175|200|250|300|350|400|450|500 | ≈3.02 |
| TCH60M.100.R | 100 | 126 | 135|150|175|200|250|300|350|400|450|500 | ≈3.20 |
| TCH60M.125.R | 125 | 151 | 135|150|175|200|250|300|350|400|450|500 | ≈3.37 |
| TCH60M.150.R | 150 | 176 | 135|150|175|200|250|300|350|400|450|500 | ≈3.55 |
| TCH60M.175.R | 175 | 201 | 135|150|175|200|250|300|350|400|450|500 | ≈ 3.73 |
| TCH60M.200.R | 200 | 226 | 135|150|175|200|250|300|350|400|450|500 | ≈ 3.91 |
| TCH60M.225.R | 225 | 251 | 135|150|175|200|250|300|350|400|450|500 | ≈4.10 |
| TCH60M.250.R | 250 | 276 | 135|150|175|200|250|300|350|400|450|500 | ≈ 4.27 |
| TCH60M.275.R | 275 | 301 | 135|150|175|200|250|300|350|400|450|500 | ≈ 4.46 |
| TCH60M.300.R | 300 | 326 | 135|150|175|200|250|300|350|400|450|500 | ≈4.64 |
| TCH60M.325.R | 325 | 351 | 135|150|175|200|250|300|350|400|450|500 | ≈ 4.82 |
| TCH60M.350.R | 350 | 376 | 135|150|175|200|250|300|350|400|450|500 | ≈4.98 |
| TCH60M.400.R | 400 | 426 | 135|150|175|200|250|300|350|400|450|500 | ≈5.34 |
| TCH60M.450.R* | 450 | 476 | 135|150|175|200|250|300|350|400|450|500 | ≈5.69 |
| TCH60M.500.R* | 500 | 526 | 135|150|175|200|250|300|350|400|450|500 | ≈6.05 |
